Section 5 - Implementing Insertion

5A.5.1 Proper Placement of Rebalancing Code

scenic picIn both insertion and deletion there is an important idea that you need to understand if you are to really have a solid feeling about the success of your rebalancing. As with all recursion, we do have to have the faith that things are perfect at the deeper levels of recursion, and we only have to explicitly care for the current level. In other words, it is okay for us to assume all is well at the lower levels, but we have to manually deal with the current level. That's really old recursion wisdom.

New for us today, though, is the idea that when we insert or remove anything from a tree, we have to fix things from the bottom up, i.e., repair and rebalance from the point of insertion/deletion, on the path upward to the root. This includes adjusting the height member of each node on the path back to the root. That part might seem obvious. Anything we touch could affect parents, grandparents and higher ancestors. But to do this, we must work from the bottom-up.

Think about it. Nothing we do, actively at any node, can destroy the AVL balance or height information below that node, or on any branch that does not contain that node. So we fix things exactly at that node after the removal or insertion, because the removal or insertion might have disturbed the situation at that one node. Next, we consider that we may have messed things up above the node, too, so we take a step up to our parent, and adjust or fix anything needed on that level. We do it again and again until we hit the root. So we take an action, then back-pedal to the top of the tree, fixing the AVL condition and/or height information as we go.

Conceptually this should make sense. But to implement it cleanly, we need to let the rebalancing work in concert with the recursion which is central to all tree insertion and deletion algorithms. In short, you should always recurse first, then rebalance immediately after. This will assure that your tree is adjusted from the bottom-up.

Coding Details:

These steps -- especially following recursion with rebalancing -- assure that you will be restoring balance to your entire tree in each operation.

Here is an abstraction of this idea in an imaginary operation remsert() which could be remove() or insert().

bool FHavlTree<Comparable>::remsert( const Comparable & x, FHs_treeNode<Comparable> * & root )
{
   ...

   // recurse
   if ( !remsert(x, root->lftChild) )
      return false;

   // follow recursion with rebalancing (rotations)
   < rebalancing code - do a rotation centered at root >
   ...

}

And to see this in a larger context, here is a full outline of a remsert() function definition where the balancing and height adjustments are done in the appropriate places:

template <class Comparable>
bool FHavlTree<Comparable>::remsert( const Comparable & x, FHs_treeNode<Comparable> * & root )
{
   if (root == NULL)
      < non-recursive moves >

   if (x < root->data)
   {
      if ( !remsert(x, root->lftChild) )
         return false;

      < rebalancing code - do a rotation centered at root >

   }
   else if (root->data < x)
   {
      if ( !remsert(x, root->rtChild) )
         return false;

      < rebalancing code - do a rotation centered at root >

   }

   // found the node
   else if ( < any other conditions that might require recursion > )
   {

      remsert( ... );

      < rebalancing code - do a rotation centered at root >
   }
   else
      < non-recursive moves>


   // successfully remserted and rebalanced at this and lower levels; now adjust height
   root->setHeight( max(heightOf(root->lftChild), heightOf(root->rtChild)) + 1);
   return true;
}

5A.5.2 Insertion

With this groundwork, we are ready to look at the insertion algorithm. Please pull out the basic FHsearch_tree::insert() method for comparison, since this is based on it. With the other half of your brain, compare the code to the mythological remsert() above, to verify that the rebalancing code does, indeed, appear where it should.

// private utilities for member methods
template <class Comparable>
bool FHavlTree<Comparable>::insert( const Comparable & x, FHs_treeNode<Comparable> * & root )
{
   if( root == NULL )
      root = new AvlNode<Comparable>(x, NULL, NULL);  // found a place to hang new node
   else if( x < root->data )
   {
      if ( !insert(x, root->lftChild) )
         return false;
      if(heightOf(root->lftChild) - heightOf(root->rtChild) == 2)
         if( x < root->lftChild->data )
            rotateWithLeftChild(root);
         else
            doubleWithLeftChild(root);
   }
   else if(root->data < x)
   {
      if ( !insert(x, root->rtChild) )
         return false;
      if(heightOf(root->rtChild) - heightOf(root->lftChild) == 2)
         if(root->rtChild->data < x)
            rotateWithRightChild(root);
         else
            doubleWithRightChild(root);
   }
   else
      return false;

   // successfully inserted at this or lower level; adjust height
   root->setHeight( max(heightOf(root->lftChild), heightOf(root->rtChild)) + 1);
   return true;
}

Perfunctory Observations:

Deeper Observations:
